Thank you for choosing IJOY! Please read this manual carefully to ensure proper use. For additional information regarding this product or its use, please consult your local IJOY retailer or visit our website www. ijoycig.com

PRODUCT INTRODUCTION:

Zenith 3, a new dual 20700 battery semi-mechanical box mod, with outstanding shape in hard lines and cool appearance, features a big voltage adjustable knob with 16 voltage levels(2.4V-6.9V) in limitless 360 degree and big sized fire button also adopt strong line design to match with whole kit, giving the device a unique and science fiction feeling.

Zenith 3 box mod’s chipset is designed by IWEPAL, with short-circuit protection, low power protection, battery reverse protection and power light operation and has milliseconds fire speed, and a maximum output of 300W. The mod is easy to operate, no overhung with big-sized atomizer and support USB charging, also with very good feeling in hand. 20700 battery inside makes it long battery life and 50A discharge, 6000mAh capacity. And 18650 battery adapter included as always.

Specifications:

Size: 50*35.8*92mm/0.06*0.04*0.12 inches
Stylish appearance
Unique big size fire button
Strong output
Lightning knob 2.4-6.9V infinite adjustable
East to use
Dual 20700 cells
Working voltage :6.6V-8.4V
Output Voltage: 2.4V-6.9v
Max Output Current: 50A
Quiescent current: less than 70uA

Turn on/off:

Press the fire button 5 times to turn on/off the power. The indicator light
Flash 3 times to show turn on and 5 times to show turn off.

Knob sound setting:

Press the fire button 3 times to turn on/off the knob beep sound.

Malfunction indication and protection:
1. Low Voltage Protection

Active indicator: When one battery voltage is lower than 3.4V, indicator will be red and flash 10 times then power off.
A. When one battery is lower than 3.5V, indicator will be red.
B. When one battery is lower than 3.7V, indicator will be red and green at the same time.
C. When one battery is higher than 3.7V, the green light will be on during the working.

When the device works more than 10 seconds, the output will be stopped. The device will be off automatically and users need to charge the battery.

2. PCB TOO HOT PROTECTION:

When the PCB temperature is too high, the red indicator flashes three times and the output is turned off. Until the PCB temperature dropped to normal level, the device can work again.

Important Notice:

1. When the current is short circuit or overloaded, the indicator will be red and flash 6 times, the knob beeps at the same time.
2. Rotate the knob once, it will beep once.
3. The indicator will light as breath light and off when the device fully charged.
4. Adjustable voltage knob is with limitless 360 degree design. Please do not vigorously twist it to avoid damaging the device.
5. Please use the same brand battery with the same discharge performance and battery voltage.
6. For different atomziers, users need to turn the adjustable voltage knob and transfer to the appropriate voltage outpout.
7. Maximum output up to 50A
