LUXOTIC MF Box Overview

Squonk mode

How to use LUXOTIC MF Box Kit?

1. Remove the back cover to take out e-liquid bottle.
2. Unscrew the cap of the e-liquid bottle, and then fill the e-liquid into the bottle slowly.
Note: Please do not overfill.
3. Insert the bottle into the device again and then put one high-rate 21700 or 18650 cell (with battery sleeve) into the device.
4. The way of inserting the bottle is as follows.
You can also turn it into a common box mid with the spare parts we provide in the package.

Box Mode
How to use?
1. Please take out the e-liquid bottle and keep it well.
2. As to battery usage, you can have three alternative usage such as single 18650 cell (with a battery sleeve), single 21700 cell, double 18650 cells with the help of the connecting piece.
Note: Please be careful not to use battery with torn shell for safety.

3. Put back the back cover.
4. Install your Favorite atomizer.
Note: You must not use squonk atomizer/bottom feeding atomizer

How to replace the PCBA?

We provide two different circuit boards, one is for variable voltage output and other is for direct output.

If you are a direct output pursuer, we also provide another circuit board without screen.
1. Unscrew the 6 screws on the top and bottom on the mod and keep them carefully.
2. Remove the front cover, unscrew the 7 screws on the original circuit board.
3. You can replace the original circuit board with a new one.
4. Repeat the above steps, screw on the 7 screws, then istall the front cover, and screw on the 6 screws on the mod.
Power on/off

Press the fire button 5 times in quick succession to turn on/off the device.

Vaping

Press the fire button and inhale

Switch the mode

Press the fire button three times to enter into the mode options. Then press “+” button or “-”button to switch between VW/BP/TEMP (Ni, Ti, SS)/(M1, M2, M3). Press the fire button to confirm. Once you confirm the mode, you can press the regulatory buttons to set the parameters.
Note: The temp ss mode is only suitable for stainless steel 316 coil.

Guillotine V2 Overview

How to use Guillotine V2 RDA:

1. Remove the tube to expose the base, and fix pre-made or self-build coils with cotton on the base.
2. Drip a few drops of e-liquid into the coil and cotton to make them fully saturated before use.
3. Put the atomizer tube onto the base and then put the top cup with mouthpiece on.

E-liquid Filling:
Unplug the top cap with mouthpiece, and then drip some e-liquid into the juice wells directly. After filling, fit on the top cup with mouthpiece again.

Adjustment of Air Inflow:

By rotating the atomizer tube clockwise or counterclockwise, you can adjust the airflow and get different vaping experiences.

Warranty

Please consult with your WISMEC distributors for warranty policy. We are not responsible for any damage caused by user error.

This warranty is only valid for authentic WISMEC products within warranty period from date of purchase by the end user.

Warning

1. Keep out of reach of children
2. This product is not recommended for use young people, non-smokers, pregnant or breast-feeding women, persons who are allergic/sensitive to nicotine.

Contra-indication

1. Only have your product repaired for use by Wismec. Do not attempt to repair the unit by yourself as damage or personal injury may occur.
2. Do not leave the product in high temperature or damp conditions, as this may damage the product. The appropriate operation temperature is within 0℃ to 45℃ while charging and -10℃ to 60℃ while in use。
3. Keep away from water

Possible adverse effects

1. Use of this product may cause damage to health
2. For people with adverse reaction after using this product, it is recommended to use the juice with lower nicotine content or no nicotine
